Home / Flagship Models / Apollo G3 RGB/RGBA

Apollo G3 RGB/RGBA

Flagship platform — custom order, 60-day lead

Apollo G3 RGB and RGBA — color-changing luminaires for facade, architectural, and sports lighting. RGB 600W, RGBA 1200W. DALI-2 or DMX512 controls. NEMA 4X weatherproof.

FLAGSHIP 60-day lead · Custom spec
Sports Lighting
25-year non-prorated warranty

Day Lead Time

25yr

Non-Prorated Warranty

lm/W Efficacy

NEMA 4X

IP Rating

Overview / Apollo G3 RGB/RGBA

The Apollo G3 RGB & RGBA are color-changing luminaires for facade, architectural, and sports lighting. Full-spectrum color flood lighting with wireless DALI-2 or wired DMX512 controls. Both luminaires and controller enclosure are NEMA 4X weatherproof. RGB at 600W, RGBA up to 1800W.

Platform Specs

Wattage	600W (RGB) / 1200W – 1800W (RGBA)
Lumens	RGB: R 16,979 / G 12,999 / B 7,673 lm — RGBA: R 28,800 / G 19,350 / B 14,650 / A 9,200 lm
Efficacy	62 lm/W @ 600W, 40 lm/W @ 1800W
CCT	N/A (color-changing)
Voltage	100-277VAC or 277-480VAC
IP Rating	NEMA 4X
Surge Protection	6kV (base station)
Weight	600W: 27.01"x12.12"x12.24" / 1800W: 27.56"x12.36"x15"
Controls	Wireless DALI-2 or wired DMX512 via Central Base Station
Mounting	Integrated or remote driver options
Operating Temp	-40°F to 131°F
Certifications	UL
Warranty	25 Years or 50,000 Hours Non-Prorated
